▼Features:
1. Special sound head structure design.
2. Streamlined appearance design, beautiful and generous.
3. It has the characteristics of high sensitivity, low noise, and wide dynamic range.
4. Excellent circuit and reed switch design, effectively reducing noise and switching impact.
5.The surface adopts baking varnish treatment process.
▼Technical parameters:
Monomer: pure aluminum coated small vibration capsule
Directivity: Heart-shaped
Frequency response: 40Hz-16KHz
Sensitivity: -48dB+2dB (0dB=1V/Pa at 1kHz)
Equivalent noise level: 18dBA
Maximum sound pressure level: 125dB (at 1kHz ≤1%T.H.D)
Signal to noise ratio: 60dB
Operating voltage: 48V fantasy power supply
Current consumption: 3mA
Monomer weight: about 380 grams
